Thumbnail Filmstrip of TD2650 Type III Works Barricade – Plastic/Tubular Steel Images
COMPLIANCE
- NCHRP350 Compliant: WZ-128
- MUTCD Compliant.
- All sheeting is ASTM 4956 compliant
Product Features:
- Type III barricades can be purchased as assembled units or component parts.and Legs and boards are available for individual purchase.and All TD2650 components are interchangeable.
- Breakaway Type III Works Barricade is available using Unistrut's Telespar tubing with breakaway base, bracket, and detachable feet.
- Barricade models 8 feet wide and greater include an anti-rotation stabilizer bar between uprights for increased stability.
- Breakaway base yields to impacting vehicles.and Easily detachable feet allow for efficient transportation, assembly, and storage.
- Plastic boards can accommodate reflective sheeting on both sides of boards.
- Available with 1" x 8" and 2" x 8" extruded boards.and See TD4000 for additional information.
- Accommodates two warning lights.
Product Specifications:
| Base Dimensions : | 1.750" X 1.750" X 60.00 |
| Base Material : | PSST. |
| Base Weight : | 9.4 lbs |
| Board Length : | 4', 6' , 8', 10', & 12' |
| Board Material : | UV Stabilized polymer with cold weather protection package |
| Board Thickness : | 1.00" or 2.00" |
| Board Width : | 8.00" |
| Center to Center Dimensions : | 20.00" minimum |
| Colors : | White |
| Height : | 61.50" minimum |
| Height of Bottom Panel / Board of Roadway : | 13.50" minimum |
| Height of Sheeting Above Roadway : | 61.50" minimum |
| Height of Top Board Above the Roadway : | 61.50" minimum |
| Reflective Sheeting : | Many options available |
| Type III : | YES |
| Upright Dimensions : | 1.50" X 1.50" X 62.00" |
| Upright Material : | PSST |
Download PDFs:
Product Information Sheet
Stock Number PDFS
